DISCRIPTION
1. Front panel:
1(а) 2xUSB 2.0, 1xUSB 3.0, HD AUDIO+MIC, Power, Reset, Power LED, HDD LED.;
1(b) external 5.25’’;
1(c) place for case fans.
2. Rear panel:
2(a) place for power supply;
2(b) place for case fan;
2(c) expansion slots for VGA, network card, modem, audio card etc.
3. General part: place for motherboard.
4. Internal Bays:
4(a) 2.5’’;
4(b) 3.5’’.
5. Side panel (left): p
erforation, place for case fans.
6. Side panel (right).
* Appearance and equipment of item can be supplemented or modied for the purpose of the improvement
or for improvement of product quality.
Front panel Side panel (left)
5
6
1 (а)
General part
Side panel (right)
2 (а)
2 (b)
2 (c)
4 (a)
4 (a)
3
1 (с)
1 (b)
4 (b)
4 (a)
4 (b)
4 (a)
