2gig Technologies PASSIVE INFRARED MOTION DETECTOR User Manual

Mounting the PIR with the bracket (see Figure 2)
1 UseshortPhillipsheadscrewstoscrewpartAintopartB.
2 Selecteitherthecornermount(partC)orflatwallmount(partD).
3 Mounttheselectedbracket(CorD)ataheightof7.5ft(2.3m).on
thewallusingthesuppliedlongscrewswithanchors.
4 PlacetheassemblyofpartsAandBontheshaftofbracketCorD.
5 ScrewaPhillipsheadscrewwithwasherintothetopofparBtohold
theassemblytotheshaftofbracketCorD.
6 AttachthemainbodyofthePIRtothemountedbackwithascrewat
thebottomofthecase.
Mounting the PIR without bracket (see Figure 3)
1 Forcornermountingusethesuppliedlongscrewswithanchorsand
mountthePIRcasebackusingeithertherighttwocornermount
screwholes(A)orthelefttwocornermountscrewholesandmount
thePIRbackataheightof7.5ft.(2.3m).Attachthemainbodyofthe
PIRtothemo
untedbackwiththescrewatthebottomofthePIR.
2FormountingthePIRonaflatwallusethe
suppliedlongscrewswithanchorsandmount
thePIRcasebackusingthe2wallmountscrew
holesinthecenterofthebackandmountthe
backataheightof7.5ft.(2.3m).Attachthe
mainbodyofthePI
Rtothemountedbackwith
thescrewatthebottomofthe PIR.
Using the PIR with Pets
Totakefulladvantageofthepetimmunityfeatures,dothefollowing:
1 EnsurethatthePIRismounted7.5‐8feetabovefloorlevel.
2 Settherightjumper(SENSITIVITY)tolow(default).
3 Ensurethattheleftjumper(PETIMMUNITY)issettoyourpet’s
weight.
4 DonotaimthePIRatstairsorfurniturethatyourpetcouldclimbon.
NOTE: ThePIRprovidesimmunitytofalsealarmsforanindividual
animaloragroupofanimalswhosetotalweightisequaltoorless
than55poundswhentheroomtemperatureisabove50°Fand
below90°F.Ifyouusedtheoptionalmountingbracket,ensurethat
thePIRismountedwithNOtilt.
Environmental and other Useful Information
WhilethePIRisahighlyreliableintrusiondetectiondevice,itdoesnot
guaranteeagainstburglary.Anyintrusiondeviceissubjecttocompromiseof
failuretowarnforavarietyofreasons.Considerthefollowingwheninstalling
thePIRforthefirsttimeorwhenyouaretroubleshooting:
1
ThisPIRhasbuilt‐inprotection,thatkeepsbugsfromgettingintothe
sensorareaandcausingfalsealarms.Thisdoesnotpreventinsects
fromcrawlingacrossthelensofthePIR,whichcouldtriggerthePIR.
2 Infraredenergycanbereflectedoffanyglossysurfacessuchas
mirrors,windows,floorsorcountertopswithglossyfinish,andslick
finishedconcrete.Somesurfacesreflectlessthanothers.For
example,thePIRcanseeachangeininfraredenergyoffofreflective
surfaceseveniftheheatorcoldsour
ceisnotwithinthePIRdetection
pattern.
3 Windowscannotonlyreflectinfraredenergy,buttheycanalsoallow
sunlightorlightsfromcarstopassthroughtothePIR.Forexample,a
PIRcandetectaquickchangeininfraredenergyifsunlightcomes
throughawindowandshinesonahardwoodfloor.Ifthechangein
infraredener
gyisquickenoughonthehardwoodfloor,thePIRcan
triggeranalarm.ThesameappliesifthePIRareaincludesawindow,
eventhoughthepatternofprotectioncannot“see”throughglass.
Lightsfromapassingcarcanalsopassthroughthewindowatnight
anddirectlyinthelensofthePI
R.
4 Heatingandairconditioningductsarealsoimportantbecauseifthey
blowairontoanobjectwithinthefieldofthePIR’sview,the
temperatureofthatobjectcouldchangequicklyenoughforthe
detectorto“see”achangeininfraredenergy.PIR’sCANNO Tseeair
current,onlythechangeinte
mperatureofaphysicalobject.
5 ThePIRsenseschangeintemperature;however,astheambient
temperatureoftheprotectedareaapproachesthetemperature
rangeof95°to120°F,thedetectionperformanceofthePIR
decreases.
6 EnsurethattheareayouwishthePIRtocoverisfreeofobstructions
(curtains,screens,plants,etc.)thatmayblockthepatternof
coverage.
7 Anythingthatcansw ayormoveduetoaircurrentcancauseachange
ininfraredenergywithinthefieldsofview.Draftsfromdoorsor
windowscancausethistohappen.Plants,balloons,curtainsand
hangingbasketsshouldneverbeleftinthePIR’sfieldofview.
8 DonotmountthePIRonasurfacethatallowsforanyvibration.
VibrationsnotonlycausethePIRtomovealittle,butitalsocauses
thefieldsofviewinaroomtomovewithrespectthePIR.Alittle
vibrationcancausehavocwiththePIR’sfieldofview
,thusthePIR
mayseeachangeinenergyandtriggerthealarm.
9 Aninstallationoftenrequiresthatth ePIRisaimedatthedoor.The
PIRmaydetectdoormovementbeforethedoorcontactcaninitiate
anentrydelay,causingthealarmtotrigger.IfyouinstallthePIR
facingadoor,thenwhileprogrammingthePIR,chooseanentrydelay.
10 ThePIRONLYdetectsintrusionwithinthepatternofcoverage.
11 ThePIRdoesnotprovidevolumetricareaprotection.
12 ThePIRcreatesmultiplebeamsofprotection.Intrusioncanonlybe
detectedinunobstructedareascoveredbythosebeams.
13 ThePIRcannotdetectmotionorintrusionthatoccursbehindwalls,
ceilings,floors,closeddoors,partitions,glassdoorsorwindows.
14 Tamperingwith,masking,painting,orsprayingofanymaterialonthe
PIRlensoranypartoftheopticalsystemcanimpairdetectionability.
15 ThePIR,likeotherelectricaldevices,aresubjecttocomponent
failure.EventhoughthePIR2isdesignedtolastaslongas10years,
theelectroniccomponentsaresubjecttofailure.
Specifications
FCC Compliance Statement*
Notice:Unauthorizedchangesormodificationscouldvoidtheuser’sauthoritytooperatethe
equipment.
ThisdevicecomplieswithPart15oftheFCCRulesandIndustryCanadalicense‐exemptRSS
standard(s).Operatingissubjecttothefollowingtwoconditions:(1)Thisdevicemaynotcause
harmfulinterference,and(2)thisdevicemustacceptan
yinterferencereceived,including
interferencethatmaycauseundesiredoperationofthedevice
.
2GIG Copyright © 2013. All rights reserved.
For technical support in the USA and Canada
855-2GIG-TECH (855-244-4832)
For technical support outside of the USA and Canada
Contact your regional distributor
Visit 2gig.com for a list of distributors in your region
PN 187-0727 Rev. E
A Cornermountingscrewholes
B Flatwallmountingscrewholes
C Bracketscrewholes
WirelessSignalRange 350ft.,openair,with2GIGControlPanel
CodeOutputs Alarm;AlarmRestore;Tamper;TamperRestore;Supervisory;
LowBattery
TransmitterFrequency 345,000MHz(crystalcontrolled)
TransmitterFrequencyTole ran ce ±15kHz
TransmitterBandwidth 24kHz
ModulationType AmplitudeShiftKeying‐On/OffKeying(ASK‐OOK)
UniqueIDCodes Over1milliondifferentcodecombinations
SupervisoryInterval 70minutes
PeakFieldStrength Typical50,000uV/mat3m
SensorType Quadelement
Petimmunity Selectable:15kg(33lbs)or25kg(55lbs;default)
SensitivityJumper Selectable:HIghorLow(default)
SuggestedMountingHeight 7.5ft(2.3m)
SensorRange 30ft.(9.1m)x50ft.(15.2m)
Max.HorizontalSensingAngle 90°
Dimensions(LxWxH) 3.2x2.5x1.9in.(8.12x6.35x4.82cm)
Weight(inc.battery&bracket) 3.7oz.(104.9g)
HousingMaterial ABSplasticandpoly‐carbonate
Color White
OperatingTemperature 32°to120°F(0°to49°)
RelativeHumidity 5‐95%Non‐Condensing
Battery(included,notinstalled) 1PanasonicCR123A,orequivalentLithiumbattery
RegulatoryLIstings ETL,FCCPart15,IndustryCanada
Warranty* 2years
IncludedAccessories Mountingbrackets,2longPhillip’sheadscrews,2plasticwall
anchors
