FCC statement 15.27(b)
This device should be professionally installed by a trained technician. The installer shall be responsible
for ensuring that the proper antenna is employed to comply with FCC requirements. The equipment
described herein may only be used in accordance with accessories listed in below for FCC ID numbers
RHK-G6CPE.
Operational Transmit Channels
Channel
Width
Lowest Channel (MHz) Highest Channel (MHz)
15.247 5.725-5.85GHz Band
5MHz 5730 (146) 5845 (169)
10MHz 5735 (147) 5840 (168)
Notice of FCC power compliance for transmit power settings
Channel Width Setting Maximum Transmit output power
5 MHz 24dBm
10 MHz 25dBm
Parts List & Tune-Up Information
- Surge Suppression
Ethernet Surge Suppression (optional, but required for outdoor wall penetration with cat5 by National
Electric Code standards in the United States.)
Optional Ethernet/Power Surge Suppressor – Part # H-LS-001.01 – DigitalPath, Inc
UL # 3VEO – Model DPISURG5E
- Power Supply ITE 24V DC PoE – Model FAS24000050-C44
Ferrites on power lead (QTY 1) – Steward 28A2024-0A0. Placed on cat5 cable(s) coupled together with
data/power together out from 24v DC power adapter. Included in installation package.
