Page 122 Image Server 2000 Owner’s Manual
Closed Captions
Closed Captions Records and plays CC data per EIA-608B
Control Inputs
Automation control, RS-422 VDCP; 3 ports, 9-pin female “D” connector
Other serial control, RS-422 P2, Odetics
GPI control inputs/outputs
6 optically isolated inputs, 6 open-collector outputs, 25-pin
female “D” connector
Video Networking
File interchange formats
MXF (SMPTE 377M, 378M, 381M) OP-1a, OP-1b; MPEG-2
program streams & elementary streams; DV stream (.dv or
.avi); TARGA graphics import.
Network port Gigabit Ethernet
File transfer protocol FTP
Disk Storage
Storage time (max) 170 hours max at 12 Mb/s
Capacity 480 GB to 1.6 TB
Data redundancy Hardware-generated RAID-5 utilizing 4 drives
Drive arrangement Located within enclosure, accessible behind front panel
CD-ROM drive
Internal, replaceable from front panel. (For loading operating
system and feature upgrades.)
Miscellaneous
Operating system Linux®
Front panel indicators
5 LEDs indicate Power-on, Genlock, Fan alarm, Drive alarm,
System alarm
Miscellaneous ports Keyboard, mouse, SVGA display
Cooling/Operating Temperature Forced air; Ambient operating temperature 10º to 35º C
Power
100 – 240 VAC, 50/60 Hz, 2.0 amp max. Shut down switch on
front panel; hard AC mains switch on rear panel
Physical
Mechanical 3½” x 19” x 18.5” (89 x 483 x 470 mm) H-W-D
Mounting Rack mount (2U), optional adjustable rear supports
Weight 28 lb. (12.7 Kg)
Agency approvals UL, C-UL, FCC Class A, CE
Country of origin U.S.A.
