360 Systems Image Server 2000 - Appendix O; Mechanical Drawing

Image Server 2000 Owner’s Manual Page 131
Appendix O
Mechanical Drawing
Figure 32: Dimensional Drawing
18.85
[479 mm]
18.12
[460 mm]
17.00
[432 mm]
19.00
[483 mm]
3.47
00:00:00;00
