Configuring ARP Settings 143

Configuring ARP

Settings

The Address Resolution Protocol (ARP) converts IP addresses into physical

addresses, and maps the IP address to a MAC address. ARP allows a host

to communicate with other hosts when only the IP address of its

neighbors is known.

This section includes the following sections:

■ Viewing ARP Settings

■ Defining ARP Settings

■ Removing ARP Entries
