161
The SNMP Traps Remove Page contains the following fields:
■ Checkbox (unnamed) — When checked, selects an SNMP trap for
removal. The top checkbox is used to select all SNMP traps for removal
■ Recipients IP — Displays the IP address to which the traps are sent.
■ Trap — Displays the trap type. The possible field values are:
■ SNMP V1 — Indicates that SNMP Version 1 traps are sent.
■ SNMP V2c — Indicates that SNMP Version 2 traps are sent.
■ Community String — Displays the community string of the trap
manager.
2 For each SNMP trap to be removed, check the box to the left of the row
in the table. To remove all SNMP traps, the topmost box may be checked.
3 Click . The SNMP traps are deleted, and the device is updated.
