Besides the default TPID value, you can configure only one TPID value on an Switch 4500 switch.

Examples

# Set the TPID value to 0x9100 for Ethernet 1/0/2 port.

<Sysname> system-view

System View: return to User View with Ctrl+Z.

[Sysname] interface Ethernet 1/0/2

[Sysname-Ethernet1/0/2] vlan-vpn tpid 9100
