3DR Pixhawk Mini - Page 13




GPS&I2CPORT

1(red)
SCL
+3.3V
2(blk)
SDA
+3.3V
3(blk)
VCC
+5V
4(blk)
TX3
+3.3V
5(blk)
RX3
+3.3V
6(blk)
GND
GND

POWERINPUTPORT

1(red)
VCC
+5V
2(blk)
VCC
+5V
3(blk)
CURRENT
+3.3V
4(blk)
VOLTAGE
+3.3V
5(blk)
GND
GND
6(blk)
GND
GND






