a
b
c
d
To remove the centre column, unscrew the D-Ring (a),
and the collar (b). You can then pull out the column
(c), and completely remove the collar (b). Your
Tri-Mount Plate (d) should be unscrewed from the
other end of the column, and then carefully screwed
directly to the canopy (e).
e
Basic Functionality
