Repeat step 1.4 for the other guide, and remove the cup. At this stage the earcup should look like in gure 1.4-d.
(1.4-d)
1.5 Detach the boom microphone connector from the connector jack on the left cup as shown in gure 1.5-a and 1.5-b.
(1.5-a)
(1.5-b)
1.6 Rotate the left cup 90 degrees to detach the earcup arm guide as shown in gure 1.6-a, 1.6-b and 1.6-c. Mild force is required.
(1.6-a)
(1.6-c)
(1.6-b)
