See Page 20 to view the assembly instructions for
the fitting of the device onto the bracket.
31 2
The bracket comes with the bolts supplied, as
shown above.
Present bracket to trap plate as shown, use trap
plate centre holes to insert and secure both M12
bolts that have been supplied with the bracket.
Prepare bracket to receive the device; remove
the pin supplied with the bracket.
7
ProtectA Rebel Bracket - [US-RAWB003520]
Assembling the PORTAGANTRY
RAPIDE
2200: ProtectA Rebel Bracket
