240 (T-H3J), 340 (T-H3S) and 540 (T-H3) models Service Manial
Ver. 1.00
CONFIDENTIAL
C-1. Temperature settings
When the 540 (T-H3) is connected with any 520 (T-H2) as part of an Easy-Link system, the available
set temperatures will default to what is available on a 520 (T-H2) (from 100 °F to 175 °F/185 °F as
shown below).
• Although 540 (T-H3) can be connected with the temperasture temperature
remote controller 9008172005 (TM-RE40), it cannot be connected with the
temperature remote controller 9007603005 (TM-RE30).
• Although 520 (T-H2) can be connected with the temperature remote
controller 9007603005 (TM-RE30), these cannot be connected with the
temperature remote controller 9008172005 (TM-RE40).
CAUTION
°F 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170 175
°C 38 40 43 45 50 52 55 57 60 63 65 68 70 75 77 80
Temperatures available under the Normal Temperature Mode*
*Factory setting (Default): 120 °F
°F 110 115 120 125 130 135 140 145 150 155 160 165 170 175 180 185
°C 43 45 50 52 55 57 60 63 65 68 70 75 77 80 82 85
Temperatures available under the High Temperature Mode*
*Factory setting (Default): 120 °F
See next page for details.
