240 (T-H3J), 340 (T-H3S) and 540 (T-H3) models Service Manial
Ver. 1.00
CONFIDENTIAL
14. Parts list
Item #
Part #
Description
Common parts for
other models
240, 340 and
540 models
T-H3J, T-H3S
and T-H3
models
240, 340
and 540
models
T-H3J, T-H3S
and T-H3
models
001
N/A EK159 Case assembly for Indoor models
N/A EK164 Case assembly for Outdoor models
002
319143-505 EK187 Front cover for 240 and 340 Indoor (T-H3J-DV and T-H3S-DV)
319143-506 EK188 Front cover for 240 and 340 Outdoor (T-H3J-DV and T-H3S-OS)
319143-507 EK158 Front cover for 540 Indoor (T-H3-DV)
319143-508 EK174 Front cover 540 Outdoor (T-H3-OS)
003 319143-509 EK170 Intake air port assembly
004 N/A EK162 Bracket
005 319143-510 EK190 Junction box
006 319143-511 EK171 Power suuply code assembly
007 319143-512 EK161 Back guard panel
008 319143-513 EK160 Chamber fixing plate
009 319143-018 EKH23 Condensate drain port
520,
320
T-H2-DV/OS,
T-H2S-DV/OS
050 319143-025 EW000 Screw M4×12 (W/Washer)
051 319143-325 EW001 Screw M4×10 (W/Washer)
052 319143-026 EW002 Screw M4×10 (Coated)
053 319143-060 EW003 Screw M4x10
054 319143-326 EW004 Hex head screw M4×12 (W/Washer)
055 319143-063 EW005 Hex head screw M4x8
056 N/A EW018 Pan screw M4x20
057 319143-201 EKK31 Tap tight screw M4x12 FEZN
058 319143-087 EW00A Screw M3x6
059 319143-328 EW009 Screw M4x6
060 319143-438 EKK37 Screw M4x12
061 N/A EK191 Screw M3x6
062 319143-059 EW00D Screw M4x8
063 319143-048 EM167 Wire clamp 60
910,
710,
520,
320
110,
310,
510,
110U,
310U,
510U
T-K3,
T-K3-Pro,
T-K3-SP/OS,
T-M50,
T-M32,
T-H2-DV/OS,
T-H2S-DV/OS,
T-KJr2-IN/OS,
T-K4-IN/OS,
T-D2-IN/OS,
T-KJr2U-IN/OS,
T-K4U-IN/OS,
T-D2U-IN/OS
064 N/A EK230 Screw M4x10
065 319143-330 EW00B Screw M3x6 SUS3
