A.R.I. S-050 User Manual

19
IOM S-050
5.3.6. Reassembling the Operating Valve
• Dip the head end of the Rolling Seal into the liquid soap solution [1]
• Reassemble the Operating Valve by inserting the loose end of the Rolling Seal into its designated groove in the
Body, making sure that the end of the seal and the insertion are in the direction of the arrows [2], [3].
• Insert the Float halfway into the Body [1], insert the Clamping Stem into the Rolling Seal groove of the Body;
make sure that it is inserted in the direction of the arrow [2]. Push the Float and the Clamping Stem together
downwards into the Body until they are locked [3].
3
2
1
2
3
1
