Ascotel IntelliGate 2025/2045/2065
Part 7 Operations supervision 929
4.1.4 Suppressing event messages in the configuration
mode
If the mainboard's HEX rotary switch is set on position 5 (configuration mode), no
event messages will be generated when a card is replaced.
4.2 System Event Manager SEM
The System Event Manager (SEM) is a program capable of receiving and handling
PBX event messages. It consists of the components:
• SEM Configurator
• SEM Server
•SEM Viewer
Fig. 7.14: SEM concept (general)
Event messages are sent to the SEM Server by the PBX. The SEM Server stores all
the important data in the corresponding AIMS database. This data can be
retrieved and edited using the SEM Viewer.
SEM Configurator
The SEM Configurator is used to start or end the SEM Server.
The relevant TCP port has to be activated for data transmission.
The event types can be assigned different priorities in the SEM Configurator.
The SEM Configurator is also used to set, for each individual AIMS database, the
way in which the SEM Server should respond to each incoming event message
(e.g. send e-mail, print out on a printer).
haz1194aaena0
PBX
Event
message
SEM Server
SEM Configurator
AIMS
database
Multi-user
SEM Viewer
