Ascotel IntelliGate 2025/2045/2065
Part 7 Operations supervision 937
4.4.3 Sequence of self-tests for corded terminals
Once the terminal has been checked with regard to connections, unlocking, etc.,
the self-test can be used to detect possible sources of error.
Note:
Terminal self-tests cannot be carried out on the Office 10 system termi-
nal.
Test procedure for Office 25
1. Unplug the terminal connecting line from the connection socket; with the
Foxkey on the outer left pressed down, reconnect the terminal connecting
line. Once the self-test mode has started, release the Foxkey.
All the display symbols appear.
2. Test keys: Pick up the handset and press one key after the other.
Each keystroke generates a tone in the loudspeaker.
3. To exit the self-test mode, unplug then reconnect the terminal connecting
line.
Should any irregularities occur during the self-test, contact a specialist.
Test procedure for Office 35, Office 45 with alpha keyboard (AKB) and
expansion keypad (EKP)
1. Unplug the terminal connecting line from the connection socket; with the
Foxkey on the outer left pressed down, reconnect the terminal connecting
line. Once the self-test mode has started, release the Foxkey.
The LEDs go on and off, and the display symbols alternate periodically
between lit and off.
2. With the handset off-hook, blow into the microphone.
The microphone and earpiece are connected with each other; the noise can
be heard in the earpiece.
3. Press the loudspeaker key.
The hands-free microphone is briefly connected with the earpiece and the
ambient noise is audible.
4. Test keys: Pick up the handset and press one key after the other.
Each keystroke generates a tone in the loudspeaker.
