Ascotel IntelliGate 2025/2045/2065
946 Operations supervision Part 7
Tab. 7.27: General self-test error displays
4.6.3 PBX will not start
Tab. 7.28: PBX will not start
4.6.4 Malfunction during PBX configuration
Tab. 7.29: Malfunction when configuring the PBX with AIMS in online operation using internal
access
7-segment display Description
Horizontal bars moving up and down Self-test in progress
3 horizontal bars Time-out appears, i.e. an input via BCD code is expected on
the HEX rotary switch.
E U L Emergency Upload system software
P (flashing) Software waiting for software transfer via Xmodem.
n o L I C EIM error or missing EIM card
Error description Error handling
No decimal point (DP) on mainboard status display. • Check power supply
DP not flashing, 7-segment display reads: 8, PBX will
not start up.
•Check whether
– software is loaded
– software is correctly loaded
• If basic system is defective, replace basic system
Error description Error cause / error handling
AIMS online operation cannot be activated or setup
of online connection is terminated; AIMS Configura-
tion Manager cannot therefore be accessed.
• Check connecting table (type, connector).
• Check whether internal access you want is selected
in AIMS:
– Start AIMS Shell
– Log into PBX
– Under "PBX: Activate required internal access.
• Check communication parameter settings under
Windows; if necessary, set identical to PBX side:
– IP addresses
– TCP / IP settings in the dial-up networking
– Under COM Port / set local parameters to same
settings as on PBX side
