AB MODEL 6600A SPECIFICATIONS
Type:
Continuous
Power Output
Per Channel @
20Hz – 20kHz:
Frequency
Response:
Distortion:
Hum & Noise:
Input
Sensitivity:
Input
Connectors:
Output
Connectors:
Controls &
Indicators
Damping
Factor:
Slew Rate:
Crosstalk:
Six Channel Amplifier
400W @ 8 Ohms
600W @ 4 Ohms
750W @ 2 Ohms
1200W @ 8 Ohms Bridged
1500W @ 4 Ohms Bridged
+/- 0.25dB 20Hz – 20kHz
No more than 0.1%THD or IM,
0.01W to rated output, 20Hz-20kHz
(Typically 0.01%)
101dB below rated output
(unweighted, 20kHz bandwidth)
1.0VRMS for rated output
(selectable - .775V, 1.0V, 1.5V)
¼” Phone Jack (Balanced) XLR
(Balanced)
5-way Binding posts
(Front Panel) Ac mains power
switch (breaker), power on LED,
level controls, signal/clip LED’S,
(Rear Panel) ground lift switch,
stereo/bridge switches per each two
channels, Low Pass Filter switch
(Ch6)
500:1 @ 1kHz
Closed-loop response greater than
40V/us
-80dB
Gain:
Mainframe Power
Supply:
Turn-On Delay:
Power
Requirements:
Thermal
Protection:
DC Protection:
Heatsink and
Cooling:
Construction:
Dimensions:
Unit Weight:
Shipping Weight:
34dB
Toroidal transformer, 3
separate power supplies w/
6ea 15k/uf capacitors
3 seconds
AC Mains 100-240VAC,
(120VAC from factory,
unless otherwise indicated)
50/60Hz, 32A/16A for 2
Ohm, 20A/10A for 4 Ohm
Each channels thermal
sensor activates channel
shutdown if an over-heating
condition exists.
Dc sensor activates channel
shutdown if DC condition
exists.
Dual fan, two speed cooling
utilizing massive heatsink
extrusions.
14-gauge cold-rolled steel
with 3/16” heavy aluminum
front panel
Slim line 7”height, 19”
standard rack mount width,
16 ½” depth overall (less
handles)
62 lbs (28.18kg)
67 lbs (
