Table 15: Binary inputs X324, 6U half 19”
Terminal Description ACT info
Hardware module
instance
Hardware channel
X324-1 - for input 1 BIO_3 BI1
X324-2 Binary input 1 + BIO_3 BI1
X324-3 -
X324-4 Common - for inputs 2-3
X324-5 Binary input 2 + BIO_3 BI2
X324-6 Binary input 3 + BIO_3 BI3
X324-7 -
X324-8 Common - for inputs 4-5
X324-9 Binary input 4 + BIO_3 BI4
X324-10 Binary input 5 + BIO_3 BI5
X324-11 -
X324-12 Common - for inputs 6-7
X324-13 Binary input 6 + BIO_3 BI6
X324-14 Binary input 7 + BIO_3 BI7
X324-15 -
X324-16 Common - for inputs 8-9
X324-17 Binary input 8 + BIO_3 BI8
X324-18 Binary input 9 + BIO_3 BI9
Table 16: Binary inputs X329, 6U half 19”
Terminal
Description ACT info
Hardware module
instance
Hardware channel
X329-1 - for input 1 BIO_4 BI1
X329-2 Binary input 1 + BIO_4 BI1
X329-3 -
X329-4 Common - for inputs 2-3
X329-5 Binary input 2 + BIO_4 BI2
X329-6 Binary input 3 + BIO_4 BI3
X329-7 -
X329-8 Common - for inputs 4-5
X329-9 Binary input 4 + BIO_4 BI4
X329-10 Binary input 5 + BIO_4 BI5
X329-11 -
X329-12 Common - for inputs 6-7
X329-13 Binary input 6 + BIO_4 BI6
X329-14 Binary input 7 + BIO_4 BI7
Table continues on next page
