Function name Signal type Signal name Description
SCEFRFLO.1.1 A Pre angle
PhC
Record data of bank 1 for
phase C pre-fault current angle
SCEFRFLO.1.1 A Pre value PhA Record data of bank 1 for
phase A pre-fault current
amplitude
SCEFRFLO.1.1 A Pre value PhB Record data of bank 1 for
phase B pre-fault current
amplitude
SCEFRFLO.1.1 A Pre value PhC Record data of bank 1 for
phase C pre-fault current
amplitude
SCEFRFLO.1.1 EF_VALIDITY Record data of bank 1 for
validity of earth fault location
SCEFRFLO.1.1 FAULT_LOOP Record data of bank 1 for fault
loop
SCEFRFLO.1.1
FLT_DISTANCE
Record data of bank 1 for fault
distance
SCEFRFLO.1.1 IFLT_PER_ILD Record data of bank 1 for ratio
between fault current and load
current
SCEFRFLO.1.1 PhV Flt angle
PhA
Record data of bank 1 for
phase A voltage angle during
fault
SCEFRFLO.1.1 PhV Flt angle
PhB
Record data of bank 1 for
phase B voltage angle during
fault
SCEFRFLO.1.1 PhV Flt angle
PhC
Record data of bank 1 for
phase C voltage angle during
fault
SCEFRFLO.1.1 PhV Flt value
PhA
Record data of bank 1 for
phase A voltage amplitude
during fault
SCEFRFLO.1.1 PhV Flt value
PhB
Record data of bank 1 for
phase B voltage amplitude
during fault
SCEFRFLO.1.1 PhV Flt value
PhC
Record data of bank 1 for
phase C voltage amplitude
during fault
SCEFRFLO.1.1 PhV Pre angle
PhA
Record data of bank 1 for
phase A pre-fault voltage angle
SCEFRFLO.1.1 PhV Pre angle
PhB
Record data of bank 1 for
phase B pre-fault voltage angle
SCEFRFLO.1.1 PhV Pre angle
PhC
Record data of bank 1 for
phase C pre-fault voltage angle
SCEFRFLO.1.1 PhV Pre value
PhA
Record data of bank 1 for
phase A pre-fault voltage
amplitude
SCEFRFLO.1.1 PhV Pre value
PhB
Record data of bank 1 for
phase B pre-fault voltage
amplitude
Table continues on next page
1MRS756791 A Section 2
DNP3 data mappings
630 series 31
Point List Manual
