ACH580 E-Clipse bypass and packaged drive user manual 229
Installation
ACH580
Disconnect Switch
or Circuit Breaker
Motor
Ground Lug
Fuses
P3/P4
Input
Ground Lug
Drive
Input
Terminals
Motor
Terminals
(Px1-3, Px12-3, Px1-4, Px12-4)
