122 Technical data
Ambient conditions
Environmental limits for the drive are given below. The drive is to be used in a
heated, indoor, controlled environment.
Operation
installed for stationary
use
Storage
in the protective
package
Transportation
in the protective
package
Installation site altitude For TN and TT neutral-
grounded network
systems and IT non-
corner grounded
network systems:
0 to 4000 m (13123 ft)
above sea level
For TN, TT and IT
corner-grounded
network systems:
0 to 2000 m (6561 ft)
above sea level
Above 1000 m [3281 ft]),
see page 116.
--
Air temperature -15 to +55 °C
(5 to 131 °F).
No frost
allowed. See page 116.
-40 to +70 °C
(-40 to +158 °F)
-40 to +70 °C
(-40 to +158 °F)
Relative humidity 5 to 95% Max. 95% Max. 95%
No condensation allowed. Maximum allowed relative humidity is 60% in the
presence of corrosive gases.
Contamination levels
(IEC 60721-3-3,
IEC 60721-3-2,
IEC 60721-3-1)
No conductive dust allowed.
Chemical gases:
Class 3C2
Solid particles:
Class 3S2
Chemical gases:
Class 1C2
Solid particles:
Class 1S3
Chemical gases:
Class 2C2
Solid particles:
Class 2S2
Atmospheric pressure 70 to 106 kPa
0.7 to 1.05 atmospheres
70 to 106 kPa
0.7 to 1.05 atmospheres
60 to 106 kPa
0.6 to 1.05 atmospheres
Vibration (IEC 60068-2-6.
Test Fc)
Max. 0.1 mm (0.004 in.)
(10 to 57 Hz),
max. 10 m/s
2
(33 ft/s
2
)
(57 to 150 Hz) sinusoidal
Max. 1 mm (0.04 in.)
(5 to 13.2 Hz),
max. 7 m/s
2
(23 ft/s
2
)
(13.2 to 100 Hz)
sinusoidal
Max. 3.5 mm (0.14 in.)
(2 to 9 Hz),
max. 15 m/s
2
(49 ft/s
2
)
(9 to 200 Hz) sinusoidal
Shock (IEC 60068-2-27) Not allowed Max. 100 m/s
2
(330 ft./s
2
), 11 ms
Max. 100 m/s
2
(330 ft./s
2
), 11 ms
Free fall Not allowed 100 mm (4 in.) for weight
over 100 kg (220 lb)
100 mm (4 in.) for weight
over 100 kg (220 lb)
