ABB CM-MSS

—
INSTALLATION INSTRUCTIONS
CM-MSS
Thermistor motor protection relays
Technical data:
T
a
: -25 ... +60 °C (-13...+140 °F)
IP 20
Pollution degree 3
3
1
2
4
2
COV
.11 -
1SVR 730 005 R01000
3
4
1
2
2
COV.11 -
1SVR 730 005 R01000
2CDC 253 013 F0014
2CDC 253 012 F0014
CM-xxx.xyS CM-xxx.xyP
CM-xxx.xyS CM-xxx.xyP
2CDC 253 007 F0011
CONNECT
(IN)
DISCONNECT
(OUT)
8 mm
0.315"
2 x 0.5...1.5 mm²
2 x 20...16 AWG
1 x 0.5...4.0 mm²
2 x 0.5...2.5 mm²
1 x 20...12 AWG
2 x 20...14 AWG
1 x 0.5...2.5 mm²
2 x 0.5...1.5 mm²
1 x 18...14 AWG
2 x 18...16 AWG
0.6...0.8 Nm
7.08 lb.in
DIN ISO 2380-1 Form A
0.8 x 4 mm / 0.0315 x 0.157 in
DIN ISO 8764-1 PZ 1
Ø 4.5 mm / 0.177 in
2 x 0.5...1.5 mm²
2 x 18...16 AWG
2CDC 252 014 F0015
CT/CM-S/N range, new housing
Screw terminals
Push-in terminals
8 mm
0.315"
1 x 0.5...2.5 mm²
2 x 0.5...1.5 mm²
1 x 18...14 AWG
2 x 18...16 AWG
2 x 0.5...1.5 mm²
2 x 18...16 AWG
8 mm
0.315"
DIN 46228-1-A
DIN 46228-4-E
I
e
> 2 A
→ 10 mm (0,39 in)
With products that are used following the ATEX guideline
2014/34/EU, attention should be paid to the attached
instruction sheet “Additional information and notes on safety”
Additional information relating to cULus approval:
- For use in pollution degree 2 environment or equivalent
- These devices need to be provided with a 6 A Class CC Fuse
at the supply input
Page 2/20
