ABB HT563757 Manual

Operation Manual / TPS44-F.. - TPS61-F..
Spare parts
12
View of turbocharger showing part
numbers
12.2
Page 125
April 2015 HZTL2412_EN Revision E
Part number
Description
10900
Cartridge group
42008 (in customer spare part set) Socket screw
42012 (in customer spare part set)
O-ring
51000 Turbine casing
51002
Fastening strips
51100 Exhaust bend
51105*
Metal C-ring
52400 Gas outlet flange
52406 (in customer spare part set)
Gasket
52408* Metal C-ring
56001
Nozzle ring
57200 Burst protection
57210
Burst ring
72000 Compressor casing
72011
Socket screw
72012 Fastening strips
72020
V-clamp
72041 (in customer spare part set) Counter-sunk screw with cross slotted
head
77000
Wall insert
77005 (in customer spare part set) O-ring
79000
Diffuser
81000 Filter silencer
81010 (in customer spare part set)
O-ring
82000 Axial air suction branch
82010 (in customer spare part set)
O-ring
86505(A)* Speed sensor (cable not integrated)
86505(B)*
Speed sensor (cable integrated)
86515(A)* Cable connector for 86505(A)
86515(B)*
Cable connector for 86505(B)
86526* F/I converter
86528*
Tachometer
* depends on the turbocharger specification.
