Operation Manual / TPS44-F.. - TPS61-F..
moval and installation
ing the turbocharger
Page 89
© Copyright 2016 ABB. All rights reserved.
September 2016 HZTL2412_EN Revision F
If present:
Fit speed sensor and plug in cable connector.
Adapt and fit bearing casing insulation (A).
Adapt and fit sheet metal (B) of bearing casing insulation.
Version with water-cooled bearing casing:
Remove the screw plugs from the water connections and fit the water
pipes in accordance with the enginebuilder's instructions.
