Operation Manual / TPS44-F.. - TPS61-F..
Removal and installation 7
Installing the turbocharger 7.4 Page 89
© Copyright 2016 ABB. All rights reserved.
August 2017HZTL2412_ENRevision F
If present:
τ Fit speed sensor and plug in cable connector.
τ Adapt and fit bearing casing insulation (A).
τ Adapt and fit sheet metal (B) of bearing casing insulation.
Version with water-cooled bearing casing:
τ Remove the screw plugs from the water connections and fit the water
pipes in accordance with the enginebuilder's instructions.
