Operation Manual / TPS44-F.. - TPS61-F..
Taking out of operation 9
Shutting down the turbocharger 9.1 Page 116
© Copyright 2016 ABB. All rights reserved.
August 2017HZTL2412_ENRevision F
Fitting the cover plate
τ Close the opening in the turbine casing using the cover plate (A).
τ Fasten the cover plate on the turbine casing (51000) using the fas-
tening strips (51002), Verbus Ripp® Verbusripp washers (51003) and
nuts (51007) and screw it down securely on the support.
NOTICE
Thoroughly clean the fastening strips (51002) before fitting them. Apply
high-temperature grease to the stud threads (51006).
