Operation Manual / TPS44-F.. - TPS61-F..
View of turbocharger showing part
numbers
Page 127
© Copyright 2016 ABB. All rights reserved.
September 2016 HZTL2412_EN Revision F
10900 Cartridge group
42008 (in customer spare part set) Socket screw
42012 (in customer spare part set) O-ring
51000 Turbine casing
51002 Fastening strips
51100 Exhaust bend
51105* Metal C-ring
52400 Gas outlet flange
52406 (in customer spare part set) Gasket
52408* Metal C-ring
56001 Nozzle ring
57200 Burst protection
57210 Burst ring
72000 Compressor casing
72011 Socket screw
72012 Fastening strips
72020 V-clamp
72041 (in customer spare part set) Counter-sunk screw with cross slotted
head
77000 Wall insert
77005 (in customer spare part set) O-ring
79000 Diffuser
81000 Filter silencer
81010 (in customer spare part set) O-ring
82000 Axial air suction branch
82010 (in customer spare part set) O-ring
86505(A)* Speed sensor (cable not integrated)
86505(B)* Speed sensor (cable integrated)
86515(A)* Cable connector for 86505(A)
86515(B)* Cable connector for 86505(B)
86526* F/I converter
86528* Tachometer
* depends on the turbocharger specification.
