11.7.3 Function block
IB16A
BLOCK
INP
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
OUT8
OUT9
OUT10
OUT11
OUT12
OUT13
OUT14
OUT15
OUT16
IEC09000036-1-en.vsd
IEC09000036 V1 EN
Figure 193: IB16A function block
11.7.4 Signals
Table 328: IB16A Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
INP INTEGER 0 INP
Table 329: IB16A Output signals
Name
Type Description
OUT1 BOOLEAN Output 1
OUT2 BOOLEAN Output 2
OUT3 BOOLEAN Output 3
OUT4 BOOLEAN Output 4
OUT5 BOOLEAN Output 5
OUT6 BOOLEAN Output 6
OUT7 BOOLEAN Output 7
OUT8 BOOLEAN Output 8
OUT9 BOOLEAN Output 9
OUT10 BOOLEAN Output 10
OUT11 BOOLEAN Output 11
OUT12 BOOLEAN Output 12
OUT13 BOOLEAN Output 13
Table continues on next page
