ABB Switzerland Ltd REG 316*4 1MRB520049-Uen / Rev. F
3-154
D. Underreactance function settings - MinReactance
Summary of parameters:
Text Unit Default Min. Max. Step
ParSet 4..1 P1 (Select)
Trip 00000000
Delay s 00.50 0.20 60.00 0.01
XA-Setting UN/IN -2.00 -5.00 00.00 0.01
XB-Setting UN/IN -0.50 -2.50 +2.50 0.01
MaxMin MIN (Select)
NrOfPhases 001 1 3 1
CurrentInp AnalogAddr 0
VoltageInp AnalogAddr 0
Angle deg 000 -180 180 5
BlockInp BinaryAddr F
Trip SignalAddr ER
Start SignalAddr
Explanation of parameters:
ParSet 4..1
Parameter for determining in which set of parameters a par-
ticular function is active (see Section 5.11.).
Trip
defines the tripping channel activated by the tripping output of
the function (tripping logic).
Delay
Time between the function picking up and tripping.
XA-Setting
defines the first intersection of the impedance circle with the
reactance axis (assuming a phase correction setting of 0°).
Setting restriction: |X
A
| < |X
B
|.
XB-Setting
defines the second intersection of the impedance circle with
the reactance axis
(assuming a phase correction setting of 0°).
