3.17.11.4 Settings
Table 193: SPCGAPC Non group settings (Basic)
Parameter Values (Range) Unit Step Default Description
Loc Rem restriction
0=False
1=True
1=True Local remote switch restriction
Operation mode
0=Pulsed
1=Toggle/Persistent
-1=Off
-1=Off Operation mode for generic con-
trol point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation
mode
Description SPCGAPC1 Output 1 Generic control point description
Operation mode
0=Pulsed
1=Toggle/Persistent
-1=Off
-1=Off Operation mode for generic con-
trol point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation
mode
Description SPCGAPC1 Output 2 Generic control point description
Operation mode
0=Pulsed
1=Toggle/Persistent
-1=Off
-1=Off Operation mode for generic con-
trol point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation
mode
Description SPCGAPC1 Output 3 Generic control point description
Operation mode
0=Pulsed
1=Toggle/Persistent
-1=Off
-1=Off Operation mode for generic con-
trol point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation
mode
Description SPCGAPC1 Output 4 Generic control point description
Operation mode
0=Pulsed
1=Toggle/Persistent
-1=Off
-1=Off Operation mode for generic con-
trol point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation
mode
Description SPCGAPC1 Output 5 Generic control point description
Operation mode
0=Pulsed
1=Toggle/Persistent
-1=Off
-1=Off Operation mode for generic con-
trol point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation
mode
Description SPCGAPC1 Output 6 Generic control point description
Operation mode
0=Pulsed
1=Toggle/Persistent
-1=Off
-1=Off Operation mode for generic con-
trol point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation
mode
Description SPCGAPC1 Output 7 Generic control point description
Table continues on the next page
