8.3.7 Settings
Table 957: TPOSYLTC Non group settings (Basic)
Parameter Values (Range) Unit Step Default Description
Operation
1=on
5=off
1=on Operation Off / On
Operation mode
1=NAT2INT
2=BCD2INT
3=GRAY2INT
2=BCD2INT Operation mode
selection
8.3.8 Monitored data
Table 958: TPOSYLTC Monitored data
Name Type Values (Range) Unit Description
TAP_POS INT8 -63...63 Tap position in-
dication
8.3.9 Technical data
Table 959: TPOSYLTC Technical data
Description Value
Response time for binary inputs Typically 100 ms
8.3.10 Technical revision history
Table 960: TPOSYLTC Technical revision history
Technical revision Change
B
Added new input TAP_POS
C
Internal improvement
D
Added new inputs END_TPOS_R and
END_TPOS_L
Added a new output TAP_POS
