OPOW6St1 PH PDIR 92 Three-phase directional overpower,
stage 1
OPOW6St1 PH PDOP 92 Directional overpower
OPOW6St1 PH RBRF 92 Breaker failure
OPOW6St2 PH PDIR 93 Three-phase directional overpower,
stage 2
OPOW6St2 PH PDOP 93 Directional overpower
OPOW6St2 PH RBRF 93 Breaker failure
OPOW6St3 PH PDIR 94 Three-phase directional overpower,
stage 3
OPOW6St3 PH PDOP 94 Directional overpower
OPOW6St3 PH RBRF 94 Breaker failure
OV3High PH PTOV 63 Three-phase overvoltage
protection, high-set stage
OV3Low PH PTOV 62 Three-phase overvoltage
protection, low-set stage
PREV3 PRV PPAM 55 Phase reversal protection
PSV3St1 NS PTOV 112 Negative phase sequence
overvoltage
PSV3St1 PS PTUV 112 Positive phase sequence
undervoltage
PSV3St1_1 PS PTOV 112 Positive phase sequence
overvoltage
PSV3St2 NS PTOV 113 Negative phase sequence
overvoltage
PSV3St2 PS PTUV 113 Positive phase sequence
undervoltage
PSV3St2_1 PS PTOV 113 Positive phase sequence
overvoltage
REF1A REF PDIF 102 High-impedance based restricted
earth-fault protection
REF1A REF RBRF 102 Circuit breaker failure protection of
high-impedance based restricted
earth-fault protection
ROV1High RES PTOV 45 Residual overvoltage protection,
high-set stage
ROV1Inst RES PTOV 46 Residual overvoltage protection,
instantaneous stage
ROV1Low RES PTOV 44 Residual overvoltage protection,
low-set stage
SCVST1 - RSYN 70 Synchro-check/voltage check
function stage 1
SCVST2 - RSYN 71 Synchro-check/voltage check
function stage 2
TOL3Cab CAB PTTR 47 Three-phase thermal overload
protection for cables
Table 5.-1 LN prefixes for RED500 (Continued)
Function Block
Name
IEC 61850 Logical Node Name Description
Logical Node Prefix Logical Node Class
Logical Node
Instance
(Channel Number)
