3 Configuration
General information
Most parameters for the positioner can be set locally, meaning
that configuration only needs to be performed via the local
communication interface (LCI) or FSK modem and PC in
exceptional cases.
You may also deny or restrict local modification and saving of
parameters by completely or partially blocking access to the
configuration level
(see Chapter Locks on page 9 and the description of the
Funktionsauswahl parameter page 36).
To simplify the process, the different parameters are grouped as
follows:
ID
Designator
Name
P1._
STANDARD
Standard
P2._
SETPOINT
Setpoint
P3._
ACTUATOR
Actuator
P4._
MESSAGES
Events
P5._
ALARMS
Alarms
P6._
MAN_ADJ
Manual adjustment
P7._
CTRL_PAR
Control parameters
P8._
ANLG_OUT
Analog output
P9._
DIG_OUT
Digital output
P10._
DIG_IN
Digital input
P11._
FS / IP
Factory setting, I/P-Type
The following sections provide an overview (in tabular and
graphical format) of the overall structure of the parameter
groups and parameters.
Example
Parameter (1st line
on the
display)
Display (2nd line
on the
display)
Function
Possible parameter
settings
Unit
Factory setting
P1._
STANDARD
P1.0
ACTUATOR
Actuator type
LINEAR, ROTARY
—
LINEAR
P1.1
AUTO_ADJ
Autoadjust
Command / Function is being run
—
—
P1.2
ADJ_MODE
Automatic adjustment mode
FULL, STROKE, CTRL, PAR,
ZERO_POS, LOCKED
—
FULL
P1.3
TEST
Test
Command / Function is being run
—
INACTIV
P1.4
EXIT
Return to operating level
Command / Function is being run
—
NV_SAVE
P2._
SETPOINT

ABB TZIDC Specifications

General

Input Signal	4 to 20 mA
Communication Protocol	HART
Protection Class	IP66, NEMA 4X
Enclosure Rating	IP66, NEMA 4X
Operating Temperature	-40 to 85 °C
Material	Aluminum
Mounting	Linear or rotary actuators
Housing Material	Aluminum
Weight	1.5 kg
Supply Pressure	1.4-7 bar (20-100 psi)
