Assembling of the canopy
g of the canopyg of the canopy
g of the canopy
Fix the canopy with the clips on both sides of the seat unit.
1
11
10
00
0.
. .
. Fixing and Removing of the bumper
Fixing and Removing of the bumperFixing and Removing of the bumper
Fixing and Removing of the bumper
For fixing the bumper, you have to put it into the plastic holder
located on both sides of the seat unit as shown on the picture.
For removing the bumper from the stroller take both clips to
the inner side und pull out the bumper from the fixation.
1
11
11
11
1.
. .
. Adjustment of the footrest
Adjustment of the footrestAdjustment of the footrest
Adjustment of the footrest
For adjusting the footrest you have to push both plastic
buttons. Now you can adjust the footrest. Release the buttons
when you have reached the requested position.
Page 7
