abc L-Desk - Page 11

å
Fasten the PLATES (41G) to the DESK TOP (C) exactly as
shown. Use six BLACK 9/16" LARGE HEAD SCREWS (1S).
å
NOTE: The PLATES will overhan the ede of the TOP.
å
Push four HIDDEN CAMS (1F) into the DESK TOP (C).
Step 6
Pae 11
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
1S
41G
C
1F
Arrow
