Step 8
Pae 13
å
Separate the EXTENSION SLIDES (35MC) from the EXTENSION RAILS (35MA) as
shown in the upper diaram below. Be prepared, the parts are reasy.
å
Fasten the EXTENSION RAILS (35MA) to the LEFT END (B) and UPRIGHT (D). Use four
GOLD 5/16" FLAT HEAD SCREWS (3S) throuh holes #1 and #3.
å
NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared
diaram. Then, slide the inner cartride of the EXTENSION RAIL in to find the other hole
that lines up with the hole in the END or UPRIGHT. Turn a SCREW into this hole.
å
NOTE: The EXTENSION SLIDES (35MC) will be used later for the DRAWER.
Push the black lever in and pull the SLIDE from the RAIL.
35MA
35MC
3
2
1
1
2
3
B
D
Open end
Open end
GOLD 5/16" FLAT HEAD SCREW
(4 used for the RAILS)
3S
Short ede with
HIDDEN CAMS
