Turn three CAM SCREWS (8F) into one LEFT REAR LEG (R).
å
Insert one WOOD DOWEL (15F) into the LEFT REAR LEG (R).
å
Fasten the LEFT END (B) to the LEFT REAR LEG (R). Tihten three
HIDDEN CAMS.
å
NOTE: Be sure the WOOD DOWEL in the LEG inserts into the END.
Step 15
Pae 20
R
B
R
8F
15F
Surface with
HIDDEN CAMS
These surfaces
should be even.
Anled ede
