abc L-Desk - Page 29

å
Turn three CAM SCREWS (8F) into one RIGHT REAR LEG (Q).
å
Insert one WOOD DOWEL (15F) into the RIGHT REAR LEG (Q).
å
Fasten the RIGHT REAR LEG (Q) to the RETURN END (V). Tihten
three HIDDEN CAMS.
å
NOTE: Be sure the WOOD DOWEL in the LEG inserts into the END.
å
Push three HIDDEN CAMS (1F) into the RETURN TOP (S).
Step 24
Pae 29
1F
Arrow
Q
8F
15F
Q
S
V
Anled ede
