4. SPECIFICATION
Print Mode:
Thermal Line Dot Print (8 dots/mm)
Fujitsu Printer Mechanism
Interface Options: 35mm capacity 55mm capacity
RS-232 (6 Way RJ12) only - AP1300 AP1310
RS-232 (6 Way RJ12) + Infra-red (IrDA) - AP1300-IR AP1310-IR
RS-232 (6 Way RJ12) + Bluetooth
TM
- AP1300-BT AP1310-BT
Interface Details:
RS-232 Rx, Tx, Busy, Ground, Wake-up control, Optional Trickle Charger Input
Selectable baud rates and formats (Default: 9600,N,8,1)
IrDA IrPHY V1.0, IrLAP, IrLMP, IAS, TinyTP, IrCOMM 9-wire
Bluetooth Bluetooth 1.2, Class 2 (up to 10m range)
Profiles: LM, L2CAP, RFCOMM, SDP, TCS, SPP (Serial Port Profile)
Battery Pack:
5 Cell NiMH Battery Pack (up to 1.8Ah capacity) - AP1300-BP
Charger:
Universal Input Trickle Charger (UK/Euro/USA) - BC1300
Input: 110 at 60Hz or 230V at 50Hz
Universal Fast Charger with Vehicle Input (UK/Euro/USA/Aus) - BC1300FC
Input: 100 - 240V ~ 50/60Hz or 12 –16Vdc or 24 –32Vdc
Print Speed:
50 mm/s Typical with a fully charged battery
Thermal Paper:
Paper Width = 58
+0
/
-1
mm
35mm Max Outer Diameter - 13m approx. length - (for Ap1300) - A05836TPR1
(Up to 14.5m length if using core-less paper rolls)
55mm Max Outer Diameter - 34m approx. length - (for Ap1310) - A05856TPR1
Printer Life:
10
8
print pulses or 50kms of Paper (more than 13 million print lines)
Outer Dimensions: Ap1300 Ap1310
Height (mm) 47 65
Width (mm) 92 95
Depth (mm) 108 128
Weight (g) (including Paper Roll and Battery Pack) 345 446
WARNING:
Only use ABLE Systems approved
Battery Packs and Chargers
For a Full User Guide please visit our Website:
www.able-systems.com
Revision: 1.3
Filename: ap13x0qsg13.doc
Date: 30/03/2005
