ABSTRACT LUD48-D - Technical Specifications; LUD48-D Specifications; LUD48-4 Specifications; LUD192-D Specifications

DIMENSIONS
LUD48-4
Output Current 350mA
LED Outputs 4
Max Voltage 48V
Power Consumption 75W
Channels 1-16Ch (RGB[W])
Power Input Mains 100-240VAC
Data & LED Connections RJ45
Operating Temp Range -20 to 50 °C
234mm
48.40mm
48.40 mm
265 mm
311 mm
48.40mm
185mm
TECHNICAL SPECIFICATIONS
DIMENSIONS
LUD48-D
Output Current 350mA
LED Outputs 1
Max Voltage 48V
Power Consumption 60W
Channels 1-4Ch (RGB[W])
Power Input Mains 100-240VAC
Data & LED Connections RJ45
Operating Temp Range -20 to 50 °C
sales@abstract.co.uk
www.abstract.co.uk
Open Mon - Fri 8am - 5pm
T: +44 (0)116 278 8078
64.50 mm
271.20 mm
242 mm
65.50mm
48.40mm
48.40mm
242mm
271.20mm
DIMENSIONS
LUD192-D
Output Current 350mA
LED Outputs 4
Max Voltage 48V
Power Consumption 240W
Channels 1-16Ch (RGB[W])
Power Input Mains 100-240VAC
Data & LED Connections RJ45
Operating Temp Range -20 to 50 °C
234mm
48.40mm
48.40 mm
265 mm
311 mm
265mm
311mm
