19
Frequency
868.6625 MHz
HF transmission power
10 mW (antenna input)
Tamper monitoring
Yes
Supervision monitoring
Every 4 minutes
Housing material
ABS
Subject to alterations and errors.
Position
The sensor can either be mounted flat on a wall or in a
corner. The following illustrations show the range of the
sensor.
For optimal detection, the sensor should be attached at a
height between 180 cm and 240 cm.
Monitoring
downwards
Aperture angle
Lens
Max. height = 2.40 m
Max. range = 15 m
Monitoring
downwards
