30
Beam grid set to maximum range. By
covering the upper section, the range is
reduced to 20 m.
Beam grid set to minimum range. By
covering the upper section, the range is
reduced to 6 m.
Surveillance curtain
Height: 6 m
Range: Maximum
tilting: 45°
Cover this area for
curtain surveillance
