Abus IPCS84530 Installation Guide

28
3. Connections and functions
3.1 Connections and controls
ATTENTION!
Before you begin the installation, make sure that the supply voltage and the
nominal voltage of the camera match.
Nr. Beschreibun
g
1 Power supply connector, 24 V AC
Pin assignment:
black: 24 V AC
yellow/green: GND
red: 24 V AC
2
A
udio input / outpu
t
3 2 x Alarm input, 1 x Alarm outpu
t
4 Network connector, RJ45
(
PoE+, 30 Watt
)
1
2
3
4
