• Now align the camera to the roughly desired coverage
area and tighten the fixing ring.
• Place the antenna on the connector and screw it tight.
• Use a commercially available weather-protected
installation box (width and height min. 105 mm, depth
min. 35 mm) for a waterproof installation.
• Guide the cable of the camera into the installation box
and carry out the wiring there. For further installation with
an installation box, follow the installation instructions for
this box.
