ACADEMY MSC-5576 - Page 17

Parts List - Glider
L1
LEG-GLIDE RIDER
2
L2
SEAT-GLIDE RIDER
1
J2
PVC COVERED CHAIN (PRE-ASSEMBLED)
4
J3
EYE BOLT WITH ATTACHMENT
BOLT (PRE-ASSEMBLED)
4
J4
EYE BOLT (PRE-ASSEMBLED)
4
Bracket - Glider
Hardware - Glider
N8
BOLT 1/4”*60MM
4
N9
BOLT 1/4”*148MM
2
N10
NYLON NUT 1/4”
6
N11
PLASTIC CAP (WITH LARGE WASHER)
8
N12
WASHER (1/4”)
12
R3
BRACKET
2
R8
BRACKET CLAMP
2
L5
WASHER (5/16”)
4
N3
BOLT 5/16” *83MM
4
N7
NYLON NUT 5/16”
8
