ACADEMY MSC-5576 - Page 19

Hardware – Flying Saucer
Parts List – Slide
Hardware – Slide
Part No.
Description
Quantity
F1-1
BOLT 3/8” x 3.35” (9.5mm x 85mm)
4
F2
REINFORCING STEEL SPACER
8
F3
NYLON NUT 3/8” (9.5mm)
12
F4
ARC WASHER 3/8” (9.5mm)
4
Part No.
Description
Quantity
X1-N
SLIDE SUPPORT (WITH OPENING)
1
X2-N
SLIDE SUPPORT
1
X3-N
SLIDE LEG TUBE
2
X4-N
SLIDE TOP SUPPORT BAR
1
X5-N
SLIDE FRONT SUPPORT
1
X6
SLIDE LADDER STEPS
2
Y2
SLIDE
1
Part No.
Description
Quantity
Y1
PLASTIC CONNECTOR
2
Z1
BOLT 1/4"38mm
2
Z2
BOLT 1/4" x 115mm
2
Z3
SPRING WASHER(LARGE)
4
Z4
CAP NUT 1/4"
6
Z5
CAP BOLT 1/4" x 14mm
4
Z6
SPRING WASHER (MEDIUM)
20
Z7
BOLT 1/4" x 75mm
2
Z8
BOLT 1/4" x 36mm
4
Z9
BOLT 1/4” x 46mm
4
