AREA OF INSTALLATION - SWING SET TOP BAR
STEP 1 – Assemble Top Bar of Swing Set Frame
➢ Connect Left and Middle and Right Top bars (#A1 and #A2 and #A3) together. Secure with B1, B5, B4
and B3 as shown in the enlarged diagram;
NOTE: For easier assembly, do not tighten the bolts all the way initially to allow room for adjustment. You
must go back and fully tighten all bolts after the entire swing set is assembled.
