AREA OF INSTALLATION – BASKETBALL SYSTEM
Step 17 – Assemble Basketball system
➢ Attach Basketball Hoop (#D2) to Basketball Board(#D3) front with Basketball Support Bar (#D1) to
Basketball Board (#D3) back by aligning the holes and secure with D4, D5, D6 and D7 as show in
below.
Part#
Qty
Hardware#
Qty
D2
1 PC
D4
4 PCS
D3
1 PC
D5
8 PCS
D6
4 PCS
D7
4 PCS
